DVCL153PHWH - LUT

DVCL153PHWH - Diva 150W Led 3WY White Clam

Lutron

  • $31.07 (Each)
  • $31.07 (Each)
  • $93.21 (Per 3)
  • $1,491.36 (Per 48)

Availablity: In Stock

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    DVCL153PHWH
    Manufacturer
    Lutron
    Manufacturer's Part Number
    DVCL153PHWH
    Description
    Diva 150W Led 3WY White Clam
    Dimmable Bulb, Wallbox Switch, 120 V, 150 W;600 W, 60 HZ, Dimmable CFL/Led;Incandescent/Halogen Lamp, Wall Mount, 2.94 In Length, 2.75 In Width, 4.69 In Height, White, +32 °F Operating Temperature, +104 °F Operating Temperature, 1 Yr Warranty, 0.25 LB/Ea
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Lighting Dimmers & Dimming Sys - Lighting Dimmers  Mark as Incorrect
    Suggest a New Category
    Classification
    Residential Dimmers, Motion Sensors, Controls, & Photo Cells
    UNSPSC
    N/A
    UPC/GTIN
    027557003322 / 00027557003322
    Weight per unit
    0.25 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $31.07 (Each)
    Carton
    $93.21 (Per 3)
    Standard Packaging
    $1,491.36 (Per 48)
    Resources
    Images


    DVCL153PHWH - Small Image

    DVCL153PHWH - Large Image

    DVCL153PHWH - Large Image
    Installation Sheets


    DVCL153PHWH - Installation Sheet

    DVCL153PHWH - Installation Sheet
    Attachments


    DVCL153PHWH - Specification Sheet

    DVCL153PHWH - Specification Sheet

    DVCL153PHWH - Specification Sheet
    Brochures


    DVCL153PHWH - Brochure
    Other Links


    DVCL153PHWH - Other

    DVCL153PHWH - Other

    DVCL153PHWH - Other

    DVCL153PHWH - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Lamp Type
    Dimmable Cfl/Led;Incandescent/Halogen
    Poles
    1
    Voltage Rating
    120
    amperage rating
    48.000 48.000
    Wattage
    600
    Material
    METAL/PLASTIC
    actuator
    Paddle Switch
    insulation
    Plastic
    connection
    Wire Leads
    Material, Color, and Finish
    Color
    White
    Dimensions and Weight
    Length
    2.94 in;75 mm
    Height
    4.69 in;119 mm
    Width
    2.75 in;70 mm
    Size
    4.69 in (119 mm) x 2.94 in (75 mm)
    Descriptions
    Long Description
    Dimmable Bulb, Wallbox Switch, 120 V, 150 W;600 W, 60 HZ, Dimmable CFL/Led;Incandescent/Halogen Lamp, Wall Mount, 2.94 In Length, 2.75 In Width, 4.69 In Height, White, +32 °F Operating Temperature, +104 °F Operating Temperature, 1 Yr Warranty, 0.25 LB/Ea
    extra long description
    LUT DVCL-153PH-WH DIVA CFL/LED CLAM
    Product Type
    dimmable Bulb
    Features
    C•L dimmers are UL listed for controlling a broad range of dimmable CFLs and LEDs. They offer more reliable dimming performance over standard dimmers when dimming CFLs and LEDs, and also provide full range dimming for incandescent and halogen bulbs
    Short Description
    Dimmable Bulb Wallbox Switch, 1P, 3W, CFL/LED, White, Clamshell
    Description
    DIVA 150W LED 3WY WHITE CLAM
    Special Features
    Controls 150 W dimmable LED/CFL (screw-base), 600 W incandescent, or halogen loads. Paddle turns on/off. Slide up to brighten, down to dim. Provides reliable dimming of dimmable LEDs/CFLs, as well as halogens and incandescents.
    Additional Information
    Switch Type
    Wallbox Switch
    Power Rating
    150 W;6000 W
    Mounting Type
    Wall Mount
    Maximum Operating Temperature
    +40 °C;+104 °F
    Warranty
    1 yr
    Minimum Operating Temperature
    +0 °C;+32 °F
    package quantity
    48 CA;3 PK
    Cable Size
    32 to 104
    Manufacturer Information
    Manufacturers Part Number
    DVCL153PHWH
    Brand
    Lutron
    sub brand
    Diva(R)
    GTIN
    00027557003322
    UPC
    027557003322
    Taxonomies, Classifications, and Categories
    Category Description
    Residential dimmers, motion sensors, controls, & photo cells
    Type
    Dimmer, 3-way/single-pole, clamshell packaging
    Packaging
    Weight
    0.25 lb/EA
    Weight per each
    0.25
    Carton
    3
    Package
    48
    Uses, Certifications, and Standards
    Frequency Rating
    60 Hz
    Operating Temperature
    32 to 104 F (0 to 40 C)
    environmental conditions
    Indoor use only
    Application
    Lighting Control
    Enclosure
    Plastic
    standard
    UL, CSA, NOM
    Mounting
    WALLBOX
