Home  ›  Products  ›  Telecom  ›  Distribution Devices  ›  Outlets, Jacks, & Plates  ›  WP3450WH
WP3450WH - PAS

WP3450WH - Cat 5E RJ45 T568 A/B CNCTR WH (M20)

Legrand-On-Q

  • $4.52 (Each)
  • $4.52 (Each)
  • $90.40 (Per 20)
  • $542.40 (Per 120)

Availablity: In Stock

Buy Now
QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    WP3450WH
    Manufacturer
    Legrand-On-Q
    Manufacturer's Part Number
    WP3450-WH
    Description
    Cat 5E RJ45 T568 A/B CNCTR WH (M20)
    Keystone Connector, Snap-In Connection, 5 Category Level, 1 Port, White, 1.28 In Length, 0.64 In Width, 0.87 In Height, -40 °F Operating Temperature, +158 °F Operating Temperature, 0.04 LB
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Distribution Devices - Outlets, Jacks, & Plates  Mark as Incorrect
    Suggest a New Category
    Classification
    All Data
    UNSPSC
    39121444 - RJ jack and module
    UPC/GTIN
    804428024873 / 00804428024873
    Weight per unit
    0.0391 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $4.52 (Each)
    Carton
    $90.40 (Per 20)
    Standard Packaging
    $542.40 (Per 120)
    Resources
    Images


    WP3450WH - Large Image

    WP3450WH - Small Image

    WP3450WH - Large Image

    WP3450WH - Large Image
    Specifications Sheets


    WP3450WH - Specification Sheet
    Installation Sheets


    WP3450WH - Installation Sheet
    Attachments


    WP3450WH - Specification Sheet

    WP3450WH - Specification Sheet

    WP3450WH - Specification Sheet
    Brochures


    WP3450WH - Brochure
    Other Links


    WP3450WH - Other

    WP3450WH - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    connection
    RJ45 Female
    Current Rating
    1.5 (@ 20°C)
    insulation
    500 (@ 100 VDC)
    Material, Color, and Finish
    Color
    White
    Finish
    Thermoplastic
    Dimensions and Weight
    Length
    1.28 in
    Width
    0.64 in
    Height
    0.87 in
    Size
    0.67 x 076 x 1.18 (17.02 x 19.30 x 29.97)
    Descriptions
    Product Type
    Keystone Connector
    Long Description
    Keystone Connector, Snap-In Connection, 5 Category Level, 1 Port, White, 1.28 in Length, 0.64 in Width, 0.87 in Height, -40 °F Operating Temperature, +158 °F Operating Temperature, 0.04 lb
    Features
    The vertical design of this high quality insert makes punchdown termination easy. The insert is for use in all Keystone wall plates and is available in multiple colors, as well as convenient contractor packs.
    Short Description
    Keystone Connector, 1 Port, White, High Impact Plastic
    Special Features
    RJ25 Configuration;Wall Plated Mount
    Description
    CAT 5E RJ45 T568 A/B CNCTR WH (M20)
    Additional Information
    Category Level
    5
    Number of Ports
    1
    Minimum Operating Temperature
    -40 °F
    Maximum Operating Temperature
    +158 °F
    Standards Met
    RoHS Compliant
    Connection Type
    Snap-In
    Coil Voltage
    60.000 Work Days
    Manufacturer Information
    Brand
    Legrand On-Q
    Manufacturers Part Number
    WP3450-WH
    sub brand
    Legrand-On-Q
    GTIN
    00804428024873
    UPC
    804428024873
    Taxonomies, Classifications, and Categories
    Category Description
    All Data
    Type
    RJ45 Female Cat 5e Keystone Insert
    Packaging
    Weight
    0.04 lb
    Weight per each
    0.0391
    Carton
    20
    Package
    120
    Uses, Certifications, and Standards
    environmental conditions
    0 to 93 (relative humidity, non-condensing)
    standard
    CSA, cULus, RoHS, ANSI/UL 1863, Flame-Retardant Plastic UL 94V-0
    Mounting
    Keystone opening
    Temperature Rating
    Operating Temp: 14 to 140 (-10 to 60); Storage Temp: -40 to 158 (-40 to 70)
    Application
    Residential
